I bought a pressure canner of Amazon, unfortunately the manual is entirely in Chinese.

It doesn't look like the two types of pressure canners I have learned about, which are "weighted gauge" and "dial gauge".

It has 3...things on the lid and I am not exactly sure how to operate it. Is this basically dial gauge pressure canner? What are the 3 things? Vents?

The product was fairly expensive and looks well build and judging by the temperature gauge it can reach very high pressures, so I assume, that it can be used for canning, but I am not sure how to find information on it.

It looks like this:

Top: enter image description here

Top from the side: enter image description here

From the top: enter image description here

From the bottom: enter image description here

Close Up of one of the holes: enter image description here

Part of the manual:

enter image description here

Full manual: https://photos.app.goo.gl/Tw3X3beWptUEGTLG6

Edit:

After scanning part of the manual with an OCR scanner and using google translate I learned the following: The middle valve is a safety valve. The right one is for manual release. The left one with the pins sticking out is an automatic release, possibly adjustable.



Best Answer

  1. Which valve is which?

    See labels below:

enter image description here

  1. When to use the auto valve?

    According to user manual Page 6, Section 5.7, you are supposed to move the handle on the auto valve at least twice a week to make sure it doesn't get stuck. Other than that, just leave it alone and let it do its thing. It will automatically maintain your pressure and temperature. I guess the auto valve is a calibrated device and they don't want you to touch it too often which would wear out the spring, so they give you the manual valve for routine pressure release.

    Additionally, if you see pressure rises to 0.175MPa but no steam comes out of the auto valve, then it's considered a malfunction and you should have the auto valve checked and repaired(5.6, Page 6).

  2. When to use the manual valve?

    Page 4, Section 4.3 and 4.4 says you are supposed to bend the tube down and slide it into the slot on the pot. And you should let the manual valve open until 1 minute after steam comes out of it, to purge the air. This is why you can not use the auto valve for this job: it doesn't have the tube so can not efficiently purge air from the bottom of the pot.

    Page 5, Section 4.7 recommends you don't open the manual valve until 2 minutes after pressure fully drops to avoid shooting hot water out of it. Also, rapid change in pressure and temperature can cause damage to the contents in the pot. However, if you don't want to wait, you can release the pressure immediately after cutting the power, just be careful(4.6, Page 5).

  3. When to use the safety valve?

    The manual didn't mention anything except you should have it checked every 6 months. So just leave it alone and hope you never have to activate it.

(This thing is actually a medical sterilizer. As is any electric medical devices the user manual actually includes a full EMC test standards(GB/T 17626) and results).




Pictures about "What are the 3 vents / weights on this Chinese pressure canner?"

What are the 3 vents / weights on this Chinese pressure canner? - Top view of crop anonymous barefoot female measuring weight on scales on white background
What are the 3 vents / weights on this Chinese pressure canner? - High angle of crop anonymous female measuring weight for control body against white background in studio
What are the 3 vents / weights on this Chinese pressure canner? - Plump woman in sportswear with measuring tape



How do you vent a pressure canner?

To be safe, USDA recommends that all pressure canners must be vented 10 minutes before they are pressurized. To vent a canner, leave the vent pipe (steam vent) uncovered (or manually open the petcock on some older models) after you fill the canner and lock the canner lid in place.

How do you regulate a pressure canner?

PRESSURE REGULATOR WEIGHT - All American Pressure Cookers/Canners are weighted-gauge canners. The pressure regulator weight is designed to release excess steam at 18 pounds of pressure.

What are the weights on a pressure cooker?

  • Pressure Regulator. This pressure regulator acts as a safety device to prevent pressure in excess of 15 pounds from building in the pressure canner.
  • Adjustable Pressure Regulator. (5, 10, or 15 lbs) ...
  • Vent Pipe. ...
  • Air Vent/Cover Lock. ...
  • Locking Bracket. ...
  • Sealing Ring. ...
  • Overpressure Plug. ...
  • Canning/Cooking Rack.




Upgrading Ancient Pressure Canner with Ingenious Weight System - ElementalMaker




More answers regarding what are the 3 vents / weights on this Chinese pressure canner?

Answer 2

Not a full answer, but I found the video on this page showing how to use a very similar device (no sound that I can see, and text in Chinese) on Alibaba.

It seems that the two valves with sort of rocker style heads are for steam release - you can flip these to release pressure once sterilization is complete - a spoon or fork or something similar will probably work, but it looks like some sort of tool in the video.

I suspect that the front one with what look like nuts is probably so that you can adjust the pressure and hence temperature of sterilization. I don't think the pressure gauge needs much explanation.

My only guess with respect to the hose is that it is intended to get the pressure or temperature at the point of sterilization - this is critical for medical applications; if you underestimate the temperature and your things aren't sterile, it leads to all sorts of trouble.
