What is the meaning of a circle on induction cooktop?
If you see prestige induction cooktops, all of them have a cricle over it. What is the importance of it or what does it indicate?
Does it mean the pot/wok base area, which touches the surface of induction cooktop, should be smaller than this circle? And if the cookware is larger than this circle it may not work?
This doubt rose when I tested very small bowls and pots to heat water. It worked, but when I used little large non stick items, whose bottom was either almost equal or was slightly larger, were not working, or working with start stop pause heating problem.
Best Answer
The most important part of it is to help decide where to put the pan. The second reason is to roughly decide what size pan will be OK on it.
With the size, it is very small pans which cannot work. For domestic movable units, the minimum size tends to be 12 cm. If the pot is smaller than that, the cooktop won't work.
The cooktop should always work if you place a too large pot on it. It is still not a good idea to do so, since you will get uneven heating of the food, and your pans will warp. But cookware with a sufficiently large ferromagnetic bottom (which might not be the full width of the bottom for sandwiched models) should in principle work.
Pictures about "What is the meaning of a circle on induction cooktop?"
What does a symbol mean on induction hob?
When the A symbol appears it means the automatic cooking functions are engaged, for assistance using these please click here or refer to the user manual for your specific appliance.Do induction cooktops cycle on and off?
Although both the induction and electric cooktop cycles its power on and off to stay at a chosen temperature, the electric cooktop does it inefficiently. For example: our previous electric cooktop would cycle on at 1,500 watts whether the temperature was set on \u201cLow\u201d, \u201cMedium\u201d or \u201cHigh\u201d.Why does my induction cooktop keep flashing?
If the burner control is blinking, the cooktop is not sensing the cookware. Make sure cookware is placed on the burner element and cookware is induction compatible.How do I know if my cookware is induction ready?
You can tell whether the pots and pans you're currently using are magnetic simply by holding a magnet to the bottom of a pan to see if it sticks. You can also check the underside of your cookware for the induction logo. This is an example of induction symbol.HOW TO USE INDUCTION HOB/ COOKTOP / TIPS AND TRICKS
