Induction unit makes buzzing sound

Induction unit makes buzzing sound - Gray Blue Yeti

I was fed up with the low quality electric hobs which are installed in my 1 meter wide "kitchen" (I forgot a crepe on the smaller one on the highest setting, and 25 min later it wasn't even browned, just dried a bit), so I recently bought a small induction cooking unit. It is a big improvement in terms of cooking convenience.

However, I noticed that with most cookware, it produces a strange buzzing sound. I don't mean the sound of the fan cooling the electronics. It produces a distinct fan-like sound, and I can clearly hear it when it works (it is self-regulated and doesn't blow all the time). But the buzzing occurs independently of the fan. It sounds like an old-fashioned phone, but not as loud and a bit muffled, as if the phone were under a duvet two rooms away. It definitely isn't supposed to be there (such as a warning buzzer). The device communicates its state primarily through a small number-outline display, and it also produces electronic beeping sounds to confirm the press of one of the touch sensors (really, who thought that this was a good interface for anything?! The thing is so unsuited for everyday use, they had to add annoying acoustic feedback because the normal tactile one is missing. But my accidental activation rate is still well above acceptable on all devices using it. [/rant]) and also to catch my attention if needed, such as when the overheating prevention mechanism turns the heat off. No buzzer of any kind is mentioned in the user's manual, and anyway it would be too 20th century to be included in this design.

The buzz isn't constant, it continues several seconds, then stops, then appears again, and so on. Sometimes it is completely missing. It seems to be dependent on the weight of the cookware. Once I cooked with an enamelled dutch oven, and I had no buzz at all. But with all other pieces of cookware I tried, I had the buzz. These include: a cheapish stainless steel pot, I think it has a plain thin stainless steel bottom; a good quality stainless steel pan with copper-sandwich bottom and mineral-based nonstick coating; a plain cast iron pan. I have noticed that the buzz seems to stop when I fill the cookware with enough food, and as the dutch oven weighs more than the other items, I think there might be a weight relation.

3-4 years ago I had access to another portable induction unit, and never heard such a buzz. That one was a vintage model from the mid 1970s. So if the buzz is normal for induction cooking today, why did they drop the non-buzzing technology used in this old piece?

I found an explanation on the Internet which claims that the buzz is caused by microscopic vibration of the layers of a sandwiched bottom. This cannot be the case, as the cast iron pan definitely has no sandwiched bottom, and yet it does generate the buzz.

Does anybody know what causes the buzz? Is it a malfunction of the induction unit, or is it normal to have it? And, because I find it somewhat annoying, do you have any ideas how to prevent it?

EDIT: I don't believe the explanations I have heard till now. "Poor sandwiched construction" is out of question, as it happens with a pan cast as a single piece. "Bottom vibrates against glass" sounds OK at first glance, but I put the pans on a thick fluffy cotton wool pad, and it didn't even reduce the buzz, so it couldn't be the reason. As for the fan - the sound is present before the fan switches on. Still, I am choosing an answer as the accepted one, because it tells me that it isn't a defect in my unit, and this is what I needed to know most.



Best Answer

As you probably know, induction burners produce an alternating magnetic field that induces a current in the cookware. This process can produce attractive and repulsive forces as well that cause vibrations.

The problem can be caused not only by poor sandwiched construction but by an uneven bottom surface, or loose parts or lids.

I have read that some people have successfully used silicon baking pads to dampen the sound.

This page has some useful information on the subject:

http://theinductionsite.com/proandcon.shtml




Pictures about "Induction unit makes buzzing sound"

Induction unit makes buzzing sound - Person Holding Black Audio Mixer
Induction unit makes buzzing sound -
Induction unit makes buzzing sound - Woman Walking on Park



Quick Answer about "Induction unit makes buzzing sound"

Answer: It is possible to hear a pulsing, buzzing, or clicking noise from the Induction Cooktop or Induction Range

Why is my induction cooktop buzzing?

A low humming sound can be heard while operating on high powers. It is perfectly normal and the humming. This is caused by the amount of energy that is transmitted from the appliance to the cookware. The sound will go quiet or go away when the cookware heats up or when the power is turned down.

How do I stop my induction cooktop from making noise?

Noise emission on induction hobs can only be avoided by using one-piece cooking utensils, e.g. with cast iron pans, iron/steel pans or enameled steel pans. Due to its stability, the classic cast iron pan in particular is perfectly suited for modern induction stoves.

Why is my induction stove making a high pitched noise?

High-pitched whistling noises: Can occur when two elements are used on the highest heat setting at the same time. The whistling noises disappear or become quieter when the heat setting is reduced. Fan noise: The cooktop is equipped with a fan that switches on automatically at high temperatures.

Why does my induction hob whistle?

Whistling noises can possibly be caused using one or more cooking zones with a large heating stage and the cookware made of different materials (type of construction). Humming noises can be possibly caused by using a large heating stage. Clicking noises can be possibly be heard during electronic switching operations.



Presentation 40: Why does my induction range make a humming sound?




More answers regarding induction unit makes buzzing sound

Answer 2

The phenomenon is called magnetostriction, and occurs when the oscillating magnetic field causes the cookware to change shape rapidly.

This frequency will be twice that of the electromagnetic field of the cooker, which is typically over 20kHz, which means that the base frequency of the vibrations is well into the inaudible range of the spectrum.

However, it's possible that the filters for the power of the unit isn't very well regulated, and you may well get some 50/60 Hz (depending on your mains frequency) signal modulating the HF signal. This would then show up as 100/120Hz noise, which is clearly audible.

Answer 3

For the most part and not denigrating anybody else's very valid opinions, I can definitely say that in my case the "noises" were caused by the fans getting slightly out of balance from collected grease etc. A good service and re- positioning of the fans on their axles always clears my noise problems. Do not forget that there are normally at least two fans, one for the induction coils and another smaller fan for the "electronics".

Answer 4

The hum may also be due to a faulty transformer, rectifier, or inverter. An induction cooktop requires a high-frequency alternating current to heat up the pan, and to stop the magnetic forces shifting the pan around the cooktop. This frequency is also high enough so it can't be heard, but will need to transform the energy coming out of the power socket in order to produce this high frequency. This energy is transformed using a transformer rectifier, and an inverter. If these are faulty, the frequency won't be as high, and therefore can be heard. Maybe this is what you're hearing.

Answer 5

My cook top in brand new and came supplied with saucepans and frying pan, no buzzing, but bought a new wok, which has the buzz its to do with the pots you are using. Smith and Noble is the brand that came with the cooktop.
