What does the "operating range" of a thermometer mean?

What does the "operating range" of a thermometer mean? - Thermometer on Medical Pills

http://www.thermoworks.com/pdf/thermopop_operating_instructions_web_a.pdf

The manual lists an "Operating Range" of "Between 32f to 122f". I thought this was the safe temperature for the entirety of the thermometer, but then it says " Do not expose the entire thermometer to temperatures over 190°F (88°C). " so the body can endure temperatures above 122f.

Does anyone know the guidelines about proper thermometer body (where all the electronics are) care?



Best Answer

The operating temperature range is the ambient (surrounding air) temperatures under which you can have the thermometer on, and it'll function properly (give correct readouts) and not excessively shorten its lifespan.

Almost all electronic devices can take higher temperatures when they're off. This is a combination of several things, including especially that the electronic components themselves generate heat, so when on they run hotter than the ambient temperature. Some are also more likely to be damaged when there is current running through them. Also, their electrical properties change depending on temperature—and at too-high or too-low temperatures, that may exceed the tolerances.

Normally you'd see a separate storage temperature quoted—but in this case, presumably they don't expect it to be stored above 122°F either. But rinsing it under 160°F water (it's IP66-rated, after all) should be fine—as long as its off. Boiling water, however, would not be. Nothing in the spec sheet says you couldn't run it through the dishwasher to clean it (again, while off)... but I'd ask ThermoWorks first before trying it...




Pictures about "What does the "operating range" of a thermometer mean?"

What does the "operating range" of a thermometer mean? - Girl in White and Blue Stripe Long Sleeve Shirt Holding White Smartphone
What does the "operating range" of a thermometer mean? - Close-Up Shot of Scrabble Tiles on a White Surface
What does the "operating range" of a thermometer mean? - Close-Up Shot of Scrabble Tiles on a White Surface



What is operating range in thermometer?

The range of a thermometer is the difference between the maximum and minimum temperatures that the thermometer can read. A common range for liquid-in-glass thermometers is from \u201310\xb0C to 110\xb0C.

What is the range of clinical thermometer?

Laboratory ThermometerClinical ThermometerLaboratory ThermometerThe temperature range is between 35\xb0C and 42\xb0C.The temperature range is between -10 and 110\xb0C.Serves clinical purposes and measures human body temperature.Serves lab purposes and measures anything other than human body temperature.

What is the range of mercury thermometer?

The mercury thermometer is one example of liquid thermometers. Alcohol is also used with this type of instrument. The temperature range is \u221280 to +330 \xb0C depending on the liquid.

What is the maximum range of thermometer?

Clinical Thermometer: Clinical thermometer is used to measure the body temperature. The scale of temperature is graduated from 35\xb0C to 42\xb0C and or from 94\xb0F to 108\xb0F. The temperature of human body always remains within this range and this is the range on the clinical thermometer.



Correct operating temperature for your PT Cursier




More answers regarding what does the "operating range" of a thermometer mean?

Answer 2

Looks like it means that the thermometer will function between 32 and 122 F.

So, don't expect it to function if it's in your freezer and don't expect it to function properly at temps greater than 122 F.

The difference between 122 F and 190 F is that at 122 F the thermometer won't work (possibly it will work but will have reduced accuracy) but it will still be fine and continue to function properly if you drop the temp below 122. When you hit 190 F, the plastic will likely start to melt.

Answer 3

It's the range at which it will display an accurate reading.

Or in some cases, any reading.

Update : I guess the terminology is different for this thermometer, as it says "Guaranteed accuracy ±2°F to 248°F" suggesting that it can handle 248°F ... so I'm guessing that in this case, it's talking about the ambient air temperature. (and it's possible that the 190°F limit is like the storage temperature on computers -- you can let it get to 180°F, provided you let it get back to the allowed operating range before use).
