Sous-vide without a pump using convection?
I'm currently planning on creating a sous-vide setup using an induction cooktop and a PID controller. I will be an Arduino micro-controller setup similar to this openschemes.com-manual control of induction cooktop
Most sous-vide setups use circulators that circulate and mix the water in the bath to keep uniform temperatures throughout the bath. I was wondering if a pump is required if I'll be using a pot on top of an induction cooktop. Since the heat source is at the bottom, won't the water rise naturally through convection and keep a constant temperature throughout the bath?
Best Answer
I made a sous-vide setup that uses a slow cooker and no pump.
I was able to observe as much as a 5 degree temperature gradient from the bottom to the top of the cooker. A big part of the problem was that my target food almost fills the cooker and impedes convection. I didn't measure the temperature gradient with an empty bath.
My setup worked passably well as long as my food was small and my thermometer was positioned at the same depth. I didn't enjoy the precision that commercial products have.
Obviously your setup will have a lot more power than mine. If your bath is much bigger than your target food you would have less of a temperature gradient than I did.
If your bath is much larger than your target food then convection will give you enough water circulation. Even a 5 degree drift will let you do some interesting things, however, It is one more variable to keep track of.
I was not satisfied with my setup and my next attempt will have a stronger heater as well as a circulation pump. Water pumps are cheap.
Pictures about "Sous-vide without a pump using convection?"
Can you cook sous vide without a circulator?
All you need is a digital thermometer and some Ziploc plastic bags, and you're good to go. Really! The key to cooking food successfully with the stove-top method is holding the water at a steady temperature long enough to cook the food.Can I use my oven to sous vide?
You can \u201csous vide\u201d in the oven, with or without water-bath.Can you sous vide on a stove top?
The cheapest, and least precise, way to do sous vide cooking is directly on your stove. It only requires a thermometer, some hot water, and some cold water.How do you sous vide without a thermometer?
Bring Your Water to the Appropriate Temperature The key to sous vide cooking without a cooker is a stove top method. Put a container large enough to hold your water and the food on the stove at medium-low heat. If possible, pick something with thick sides like a Dutch oven, so it will lose heat at a slower rate.How to cook steak sous vide without a machine
More answers regarding sous-vide without a pump using convection?
Answer 2
What you will be dealing with is called stratification. Given a reasonable volume of water the difference can be quite remarkable. A one metre height of water can stratify water from 20°C to 95°C as long as the water is not disturbed and heated gently, even if heated from the bottom
The simple solution is to regularly stir the water, say once every five minutes. This would be OK for items only requiring an hour in sous-vide, but for much longer this can get rather tedious
If you are targeting temperatures in the 40°C to 65°C range a small aquarium pump would suffice to stir the water. Arrange the intake tube nearly floating on top, and the output tube weighted on to the bottom. At a pinch an aquarium bubbler would help significantly too. Both these devices will cool the water somewhat, but a stove top heater should be able to keep up
Example: Using a small bubbler in a large, well-insulated chest (Rubbermaid cooler, Esky, chilly bin etc.) with around 10 l of water at 60°C, keeps the temperature within 1°C from top to bottom. Heat loss is around 1°C per 30 minutes. By adding about 0.5 l of 95°C water every 30 minutes it keeps the temperature constant over a few hours
To get precise temperature control within ±0.5°C which some sous-vide recipes recommend, you will need a PID controller. For general home use with temperature control or ±3°C you could get away with a stove top heater, with accurate power control and a thermometer control system. PID is not that hard, so you might as well add that to your controller too
