Pressure cooker missing a part. How do I fix it?
I inherited an old pressure cooker from a friend, but it seems to be missing a part. I locked it down and boiled some water in it.
So it looks like they had some tape or something over the red arrow valve. The green arrow valve never popped up, and I was unable to get any psi on the gauge. Once the water came to a boil, a vent of steam (and a bit of water) came out of the red arrow valve.
Can anyone tell me the name of the part that is needed at the red arrow?
Thanks.
I don't have the reputation to comment on your answer. Thanks for the help. The only indication of model or type is "LISTED 409A" on the bottom of the vessel. I'll be sure to get the proper pressure regulator.
Second edit. Actually found the model number. 0178107. 26091G3
Best Answer
It's good that the "green arrow valve" never popped up; that's the safety fuse, and only "pops" (destructively, and probably spraying food onto the ceiling) when the cooker pressure goes way too high.
The missing part is the pressure regulator, gauge or counterweight. The pressure cooker won't work without it. It blocks steam coming out of the vent until the steam pressure gets high enough to push the regulator up off the vent, thus limiting the internal pressure.
These are usually pretty easy to replace, as they are easy to lose.
It's important to get the right one, to use the wrong one could be very dangerous!
Your cooker is made by Presto. Presto calls that part a pressure regulator, as well as I can tell: http://www.pressurecooker-outlet.com/Presto-Pressure-Cooker-Parts.htm
Pictures about "Pressure cooker missing a part. How do I fix it?"
Can pressure cooker be repaired?
Now you can do some repairs of your pressure cooker yourself and get back to cooking in just 5 minutes! All you need is a screwdriver \u2013 the other parts and tools are all there in the Hawkins Repair Kit. No more risk of using spurious parts, incurring repair costs or dealing with untrained, unscrupulous mechanics.What are the parts of pressure cooker?
An electric pressure cooker consists of three parts, the lid, inner pot and housing unit. The most important things to know about electric pressure cookers are the safety valves and smart control box. The inner pot is a removable cooking pot. It is generally made from aluminum or stainless steel.How do you fix a rubber pressure cooker?
Don't operate a pressure cooker without its rubber gasket in place. The gasket is the rubber ring seal that goes on the underside of the lid. It helps to create a seal, enabling pressure to build up. When the rubber gasket gets hard or sticky, it's time to replace it.Reasons your Instant Pot WON'T Come to Pressure--And how to fix it!
